SUHxxx Ultrasonic flow meter without display
34 © ifm electronic gmbh 11661449 / 01 07 / 2025
10.3.10 Totaliser reset
The totalisers Vol.1 and Vol.2 can be reset in different ways:
Type of reset Parameter
1. Manual reset Command Reset Totaliser x
2. Time-controlled reset Reset Totaliser x =
• … h (hours)
• … d (days)
• … w (weeks)
3. Reset via external signal • ou2 = In.D
• DIn2:
– +EDG = reset for rising edge
– -EDG = reset for falling edge
– HIGH = reset for high signal
– LOW = reset for low signal
4. Reset via overflow
(maximum display range is reached)
Reset Totaliser x = OFF
Totaliser Vol.L cannot be reset.
If totaliser Vol.1 is reset in one of the above ways, the output is also reset in the case of consumed
quantity monitoring.
Switching signal totaliser [ 25].
10.3.11 Counting method of the totalisers
The totalisers Vol.1 and Vol.2 take account of the flow direction when totalising the consumed quantity.
The following counting methods can be defined via the parameter FProx:
FProx Counting method
0+ Negative volumetric flow values (against the marked flow direction) are not taken into ac-
count for totalling.
-0 Positive volumetric flow values (corresponding to the marked flow direction) are not taken
into account for totalling.
-+ Negative flow values are subtracted from the consumed quantity.
++ All volumetric flow values are totalled irrespective of the volumetric flow direction.
Tab.2: Counting method of the totalisers
The counting method of Vol.L cannot be set. The lifetime totaliser totals all volumetric flow quantities
irrespective of the flow direction.
The counting method affects the output signals for consumed quantity monitoring.
Consumed quantity monitoring (totaliser function) [ 24].
