SU2x5x SU6x5x SU7x5x SU8x5x SU9x5x Ultrasonic flow meter
26
[FOUx] Process values [SELx] Output signal Explanation
On All process values In case of a fault, the output goes to
21.5 mA (current output) or 4.9 V / 11 V
(voltage output).
As soon as a defective process value
is present, the device sets all process
values to invalid.
OFF All process values In case of a fault, the output goes to 3.5
mA (current output) or 0.25 V / 0 V
(voltage output).
OU Flow In case of a fault, the output goes to 3.5
mA (current output) or 0.25 V / 0 V
(voltage output).
If the process value “Flow” is defective,
the device continues to provide the
process value “Temperature”.
Temperature In case of a fault, the output goes to
21.5 mA (current output) or 4.9 V / 11 V
(voltage output).
If the process value “Temperature” is
defective, the device continues to pro-
vide the process value “Flow”.
• Frequency signal:
[FOUx] Process values [SELx] Output signal Explanation
On All process values In case of an error the output goes to
130% of [FrPx].
As soon as a defective process value
is present, the device sets all process
values to invalid.
OFF All process values In case of an error the output goes to
0Hz.
OU Flow In case of an error the output goes to
0Hz.
If the process value “Flow” is defective,
the device continues to provide the
process value “Temperature”.
Temperature In case of an error the output goes to
130% of [FrPx].
If the process value “Temperature” is
defective, the device continues to pro-
vide the process value “Flow”.
The parameter [FOU] has no influence on the pulse signal, the diagnostic signals for flow
direction and signal quality and the IO-Link process data transmission.
9.2.7 Output off
The output signal can be switched off via the parameter [oux] = [OFF]. The output then goes to high
impedance.
Communication via the IO-Link interface on OUT1 remains active.
9.3 Application configuration
The chapter describes the setting options for adaptation to your specific application.
9.3.1 Standard unit of measurement
It is possible to set a unit of measurement for each process value, on which further parameter settings
will be based.
Selectable values:
• Flow [uni.F]: l/min; l/h; m
3
/h; m/s; gal/min; gal/h; ft/s; oz/min.
• Temperature [uni.T]: °C or °F.
9.3.2 Process value for OUT1 and OUT2
The process value to be output via OUTx can be selected using the parameter [SELx].
Selectable values:
• [FLOW]: Flow
• [TEMP]: Temperature
