Encoder (SR) with CANopen interface RM900S RM901S RM902S RM903S
11
6 Mounting
WARNING
Failure of the safety sub-function of the encoder (SR) caused by an unsafe shaft drive.
u The system manufacturer must take design measures to ensure that the encoder is
driven by the shaft and that the encoder is secured at all times (fault exclusion). The
specifications of IEC 61800-5-2:2017 “Adjustable speed electrical power drive systems –
Safety requirements, Table D.8 - Motion and position feedback sensors” must be
complied with.
u Suitable overdimensioning can also be used to justify fault exclusions for mechanical
connection elements (see ISO 13849-1:2023, section 6.1.10.3 and ISO 13849-2:2012,
Annex A).
u The system manufacturer must install the encoder (SR) correctly to ensure that it is
always driven by the axis to be measured and is not overloaded.
u When attaching, observe the requirements and acceptance conditions of the overall
system.
u Secure all fastening screws against unintentional loosening.
u Avoid shocks (e.g. hammer blows) to the shaft during installation.
u Avoid permanent water deposits on the shaft. Do not mount the shaft vertically upwards.
WARNING
Ingress of solids, fluids, gases or chemical substances.
w The shaft is not protected against the ingress of solids, fluids, gases or chemical
substances.
u Measures must be taken to ensure that none of these media are in the area of the shaft.
Use at low ambient temperatures results in increased values for the starting torque. This has to be
taken into account during installation/shaft drive (→ Chapter Shaft torques).
6.1 Solid shaft
6.1.1 Installation of the coupling
u Use a coupling suitable for the application with a positive connection (→ Accessories →
www.ifm.com).
Pay attention to the following notes and installation instructions of the coupling manufacturer
• The coupling must be suitable for the specified speed and possible axial displacement
• Installation on a grease-free shaft
• Do not load the coupling and the encoder axially.
• Tighten the clamp screws to the torque defined by the coupling manufacturer.
• Secure the screws of the coupling against unintentional loosening.
Observe the safety designs from the IEC 61800-5-3 standard.
w (→ Table G.1 - Encoder (SR) – Mechanical fault list and fault exclusions).
