PY1705 PY1707 PY1709 PY1717 PY1718 PY1726 PY1728 PY1789 Electronic pressure sensor
8
4 Function
Measuring cell:
• The system pressure is measured by a ceramic capacitive measuring system.
• The sealing of the ceramic measuring cell is free of elastomers and thus maintenance-free.
• The medium temperature is recorded on the back of the ceramic measuring cell: Accuracy
calculation formula Ò Data sheet.
Signal transmission:
• The unit can be operated in SIO mode (standard input-output ) or in IO-Link mode. The basic
operation mode is SIO. When connected to an IO-Link master, the unit automatically switches to
IO-Link mode. An additional manual switching is not required.
SIO-Mode:
• Analogue signal measured pressure value 4-20 mA (pin 2).
• Switching information (pin 4).
IO-Link mode:
• Measured pressure value
• Measured temperature value
• Exceeding and falling below the limits of the measuring range
• Device status
• Switching information
• Parameter setting
• Device diagnostics (events)
4.1 IO-Link
IO-Link is a communication system for connecting intelligent sensors and actuators to automation
systems. IO-Link is standardised in the IEC 61131-9 standard.
General information on IO-Link at io-link.ifm
Input Output Device Description (IODD) with all parameters, process data and detailed
descriptions of the device at documentation.ifm.com
IO-Link offers the following advantages:
• Interference-free transmission of all data and process values
• Parameter setting in the running process or presetting outside the application
• Parameters for identifying the connected devices in the system
• Additional parameters and diagnostic functions
• Automatic backup and restore of parameter sets in case of device replacement (data storage)
• Logging of parameter sets, process values and events
• Device description file (IODD - Input Output Device Description) for easy project planning
• Standardised electrical connection
• Remote maintenance
