Je bekijkt pagina 13 van 33
The pressure sensor detects the system pressure and converts it into
an analogue output signal (4 ... 20mA). The measuring range can be
scaled to up to 25% of the value of the measuring range (→ page 19).
It is also indicated:
• System pressure above the measuring range: output signal > 20mA.
• System pressure below the measuring range: output signal drops to
max. 3.2mA (depending on the scaling).
Applications (Type of pressure: relative pressure):
Avoid static and dynamic overpressure exceeding the given over-
load pressure.
Even if the bursting pressure is exceeded only for a short time
the unit can be destroyed (danger of injuries)!
The unit is ready for operation when delivered.
Factory preset: not scaled (ASP = 0bar; AEP = 100% of the final value
of the measuring range).
13
1
ENGLISH
Function and features
Bursting
pressure
Permissible
overl. pressure
Measuring
range
Order no.
PM2053
-1.0 ... 25 100 350
-15 ... 363 1450 5070
-0.1 ... 2.5 10 35
bar
PSI
MPa
bar
PSI
kPa
bar
PSI
kPa
mbar
PSI
kPa
PM2054
-0.5 ... 10 50 150
-7 ... 145 725 2175
-50 ... 1000 5000 (5MPa) 15000 (15MPa)
PM2056
-0.13 ... 2.50 20 50
-1.8 ... 36.3 290 725
-13 ... 250 2000 (2MPa) 5000 (5MPa)
PM2057
-50 ... 1000 10000 (10bar) 30000 (30bar)
-0.7 ... 14.5 145 450
-5.0 ... 100 1000 (1MPa) 3000 (3MPa)
