PG17xx Electronic manometer
36
If an invalid measured value outside the measuring range is using for teaching, [UL] or [OL] and
[FAIL] are displayed alternately. The value is not adopted.
10.3.3 Output off
The output signals can be switched off as follows:
Output OUT1:
• [ou1] = [OFF]: The physical output OUT1 becomes highly resistive so that no signal can be output.
The setting has no effect when using the IO-Link interface.
• [ModE] = [Deactivated]: The selected switching signal channel is deactivated (Ò Digital switching
signal/31). The setting has no effect when using the hardware output.
Only switching signal channel SSC1.1 can be deactivated via the device keys.
Output OUT2:
• [ou2] = [OFF]: The physical output OUT2 becomes highly resistive so that no signal can be output.
10.3.3.1 Parameter setting via device keys: Output off
u Go to the [EF] > [OUTx] menu.
u Select [oux] and set [OFF].
- or –
u Select [EF] > [OU1] > [ModE] and set [DEac].
10.4 Application configuration
10.4.1 Standard unit of measurement
A standard unit of measurement to be displayed with the process value can be selected. All further
parameter settings are based on this unit.
Changing the unit has no effect on the IO-Link process value, which is always transmitted in the SI
unit.
Selectable values:
• Pressure [uni.P]: bar or mbar (Ò Technical data at ifm.com), psi
• Temperature [uni.T]: °C or °F.
The pressure unit is indicated by an LED below the digital display. The temperature unit is
indicated in the digital display behind the process value.
u Select the unit of measurement before configuring further parameters for OUTx.
10.4.1.1 Parameter setting via device buttons: Standard unit of measurement
u Call up the menu [EF] > [CFG].
u Select [uni.x] and set the unit of measurement.
10.4.2 Error behaviour of the outputs
The response of the OUTx output in case of a fault can be set via the parameter [FOUx]. The following
signals are output in case of a fault:
• Switching signal:
– On: The output switches ON in case of a fault.
