Electronic manometer PG17xx
37
– OFF: The output switches OFF in case of a fault.
• Analogue signal:
– On: The analogue signal goes to 21.5 mA.
– OFF: The analogue signal goes to 3.5 mA.
10.4.2.1 Parameter setting via unit keys: Error behaviour of the outputs
u Go to [EF] > [OUx].
u Select [FOUx] and set the error behaviour for OUTx.
10.4.3 Damping
The set damping constant stabilises the output signals. Abrupt changes in the physical process values
are smoothed out.
This concerns the outputs, the display and the process value transmission via the IO-Link interface.
The damping constant is added to the response time of the sensor (Ò Technical data).
The UL and OL signals are defined under consideration of the damping time.
[dAP] influences the maximum switching frequency:
f
max
=
1
2 x dAP
.
Measured value damping only has an effect on the process value pressure.
Selectable values:
• [dAP] = damping time for switching signal, display and IO-Link signal (63% rise time)
• [dAA] = damping time for the analogue signal (63% rise time)
10.4.3.1 Parameter setting via the device keys: Damping
Switching output:
u Call up the menu [EF] > [CFG].
u Select [dAP.P] and set a damping time between 0…99.99 seconds.
Analogue output:
u Go to the [EF] > [OUT2] menu.
u Select [dAA] and set a damping time between 0…99.99 seconds.
10.4.4 Output polarity of the switching outputs
The output polarity is set via the parameter [P-n].
• [PnP]: The switching output is positive switching.
• [nPn]: The switching output is negative switching.
10.4.4.1 Parameter setting via unit keys: Output polarity
u Call up the menu [EF] > [CFG].
u Select [P-n] and set [PnP] or [nPn].
