Pressure-resistant position sensor for hydraulic cylinders MFH2xx
© ifm electronic gmbh 11660562 / 00 06 / 2025 27
12 Troubleshooting
Display / problem Cause / remedy
The yellow switching status LED flashes at 5Hz. Short circuit or overload at OUT1 and/or OUT2.
Remove the short circuit.
Error after switch point Teach SPx:
The piston is in the end position and a switch point teach
has been carried out. When the piston returns to the end
position, the device will not switch.
With the switch point teach, the switch point is shifted by
the hysteresis to the teach point. Depending on the sig-
nal direction, the teach point is therefore outside the op-
erating range.
Manually reduce the switch point by 2 times the hys-
teresis.
IO-Link event “block parameter setting error”:
The device does not accept the values for configuring a
switching channel.
The switch points SP1 and/or SP2 were set outside the
setting range. However, in modes with hysteresis, the
switch points must be further within the limits of the set-
ting range by at least the value of the hysteresis.
Reduce hysteresis.
Shift the switch points further inwards.
