8
5.2 Locator for mounting accessories
The back of the device has been prepared for fixing the mounting
accessories� The 11 M5 tapped holes have a thread length of 8 mm�
188
120
40,5
30 3030
81
Locator for mounting accessories (back of the unit)
Screw the mounting accessories to the device applying 2 Nm�
5.3 Rotate cable connection
The cable connection of the device can be rotated by 180 degrees� This
allows that the cables from the device can be laid from the top or the
bottom�
