Machine light RGBW DV3011
9
6 Operation
The device has four digital inputs. The colour of the LED strip can be set individually using the digital
inputs.
The following properties are assigned to the four digital inputs:
• Input a - red
• Input b - green
• Input c - blue
• Input d - white
By triggering the four inputs correspondingly, the user can determine the colour of the LED strip.
Input d
(white)
Input c
(blue)
Input b
(green)
Input a
(red)
Colour
0 0 0 0 off
0 0 0 1 red
0 0 1 0 green
0 0 1 1 orange
0 1 0 0 blue
0 1 0 1 violet
0 1 1 0 turquoise
0 1 1 1 white (RGB mix)
1 0 0 0 white (dedicated white channel,
lower current consumption)
