DTI801 DTI901 DTI911 DTI921
35
Command
value
EPC length
EPC 0 to 15
Memory
bank
Address
Length
Data 0to27
Block
counter
Status bit
“Cmd Start”
Command
value
Data 0to27
Block
counter
Error value
Status bit
“Cmd End”
Status bit
“Cmd Start”
Device car-
ries out pre-
set com-
mand
0x00 0x00 0x00
00
0x00 0x00
00
0x00
00
0x00 0x00 0 0x00 Sin-
gle
EPC
0x00 0x00 0 0
9.10 Operating mode "LOCK DATA”
In the “LOCK DATA” operating mode, a memory area is locked on an ID tag. A password is assigned
for the locked memory area. The password is necessary if the memory area is to be written to. The
field “Lock action” determines the state:
• Memory area locked: “Lock action = 0x01”
• Memory area not locked: “Lock action = 0x00”
Locking the memory area:
u The controller sets the command value “0x08”, the password (length 4 bytes) and the “Lock action”
in the process data output image. To identify the ID tag, the EPC and its length are also necessary.
w The “Memory Bank” field sets which memory bank is to be locked:
EPC:“0x01“
USER:“0x03“
u The controller starts the write operation with the status bit “Cmd Start”.
w The device acknowledges the start of the operation by setting the status bit “Cmd Start
Acknowledge” in the process data input image.
w The device sets the status bit “Cmd End” with the end of the operation.
u The locking is terminated.
If the operation was unsuccessful, the device sets the error value and the status bit "Cmd End"
in the process image. Data transfer is interrupted.
Byte Process data output Process data input
0 Command value=0x08 Command value=0x08
1 Status Status
2 ignored 0x00
3 Length of EPC 0x00
4 EPC 0 0x00
5 EPC 1 0x00
6 EPC 2 0x00
7 EPC 3 0x00
8 EPC 4 0x00
9 EPC 5 0x00
10 EPC 6 0x00
11 EPC 7 0x00
12 EPC 8 0x00
13 EPC 9 0x00
14 EPC 10 0x00
15 EPC 11 0x00
16 EPC 12 0x00
