Je bekijkt pagina 21 van 46
DTI801 DTI901 DTI911 DTI921
21
Byte Process data output Process data input
5 Ignored Data 3
6 Ignored Data 4
7 Ignored Data 5
8 Ignored Data 6
9 Ignored Data 7
10 Ignored Data 8
11 Ignored Data 9
12 Ignored Data 10
13 Ignored Data 11
14 Ignored Data 12
15 Ignored Data 13
16 Ignored Data 14
17 Ignored Data 15
18 Ignored Data 16
19 Ignored Data 17
20 Ignored Data 18
21 Ignored Data 19
22 Ignored Data 20
23 Ignored Data 21
24 Ignored Data 22
25 Ignored Data 23
26 Ignored Data 24
27 Ignored Data 25
28 Ignored Data 26
29 Ignored Data 27
30 Ignored Block counter
31 Ignored Error value
9.4 Operating Mode “WRITE DATA AUTO"
In the “WRITE DATA AUTO” operating mode the data to be written is defined by the process data
output image. If an ID tag enters the detection range, the data bytes are written to the ID tag with the
address and length.
The memory area is set by the following parameters:
• "Auto-Read/Write Address",
• "Auto-Read/Write Data Length” and
• "Auto-Read/Write Memory Bank".
Max. 28 bytes can be defined in the process data output image (data 0 to 27). If a shorter length is
defined in the parameter “Auto-Read/Write Data Length”, the other data bytes are ignored and not
written to the ID tag. The write command is started with the status bit “Cmd Start”.
If writing was successful, the written data is mirrored in the process data input image, the block
counter is increased and the status bit “Cmd End” is set.
