AL4322 Remote I/O module 8DO 8DI
46
9.2.4.6 Reading the switching signal signals
Available data:
Name Description Value range Access
[state] State of the switching signal • False: OFF
• True: ON
ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the current states of the switching signals of the main counter (main) and
the batch counter (batch) of the port.
9.2.4.7 Controlling the switching signal channels
Available data:
Name Description Value range Access
[reset_latch] Reset the switching signal (only ef-
fective if switch-point mode = Latch)
• Inactive: set inactive status
• Active: set active status
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Processdata] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the control signals for the switching channels of the main counter (main)
and the batch counter (batch) of the port.
u Set the status of the switching signals.
u Click on to save the changes.
9.2.4.8 Reading status and diagnostic information
Available information:
Name Description Value range Access
[temperature] Device temperature (value in °C) E.g. 52: 52°C ro
1
[voltage_us] Present voltage value of device supply
US (value in mV)
E.g. 25236: 25236mV ro
1
[current_us] Present current value of device supply
US (value in mA)
E.g. 82: 82mA ro
1
[supervisionstatus_us] Status of device supply US • OK: no error
• Fault: error
ro
1
[voltage_ua] Voltage value of device supply UA (value
in mV)
E.g. 25236: 25236mV ro
1
[current_ua_upper] Upper current value of device supply UA
(value in mA)
E.g. 2: 2mA ro
1
[current_ua_lower] Lower current value of device supply UA
(value in mA)
E.g. 82: 82mA ro
1
[supervisionstatus_ua] Status of device supply UA • OK: no error
• Fault: error
ro
1
