AL4322 Remote I/O module 8DO 8DI
40
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 5...8).
w The menu page shows the current settings of the port’s counter module.
u Set the parameters.
u Click on to save the changes.
w The counter modules are configured.
9.2.3.4 Configuring the switching signal channels
u Observe the notes on switching signal channels: Switching signal channels (Ò/14)
Available parameters:
Name Description Value range Access
[mode] Switching mode of switching channel • Deactivated: switching channel
deactivated (default)
• Single Point: single point mode
• Latch: latch mode
• Two Point: two point mode
• Window: window mode
rw
1
[logic] Switching logic of switching channel • Active High: high active (default)
• Active Low: low active
rw
1
[sp1] Setpoint 1 • 0: 0 (default)
…
• 4294967295: 4294967295
rw
1
[sp2] Setpoint 2 • 0: 0 (default)
…
• 4294967295: 4294967295
rw
1
[single_point_edge] Defines whether switching channel
should react to rising or falling counter
values
• Rising Counter Value: rising edge
(default)
• Falling Counter Value: falling edge
rw
1
[switch_delay] Switching delay (value in ms) • 0: 0ms (default)
…
• 65535: 65535ms
rw
1
[reset_delay] Reset delay (value in ms) • 0: 0ms (default)
…
• 65535: 65535ms
rw
1
[hysteresis] Hysteresis • 0: 0 (default)
…
• 65535: 65535
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the current settings of the switching channels of the main counter
([main]) and the batch counter ([batch]) of the port.
u Set the parameters.
u Click on to save the changes.
w The switching signal channels are configured.
