AL4322 Remote I/O module 8DO 8DI
38
9.2.3.1 Reading the configuration of the EtherNet/IP interface
Available parameters:
Name Description Values Access
[network] > [dhcp] Status of the DHCP client • Static IP: Static IP address
• DHCP: DHCP (Dynamic Host
Configuration protocol)
• BOOTP: BOOTP (Bootstrap
Protocol)
ro
1
[network] > [ipaddress] IP address of the Ethernet interface e.g. 192.200.0.100
• 192.168.1.250 (default)
ro
1
[network] > [subnetmask] Subnet mask of the network segment e.g. 255.255.192.0
• 255.255.255.0 (default)
ro
1
[network] > [ipdefaultgateway] IP address of the network gateway e.g. 192.200.63.1
• 0.0.0.0 (default)
ro
1
[network] > [macaddress] MAC address of the Ethernet interface e.g. 00:02:01:0E:10:7C ro
1
1
Read only
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [Fieldbussetup] submenu.
w The menu page displays the current configuration of the EtherNet/IP interface.
9.2.3.2 Configuring input filters
u Observe the notes on input filters: Digital input filters (Ò/9)
Available parameters:
Name Description Value range Access
[debounce_time] Debounce time (= value * 0.1milliseconds) • 0: 0ms (default)
…
• 500: 50 ms
rw
1
[hold_time] Hold time (= value * 0.1milliseconds) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
[hold_level] Hold level • low: hold LOW
• high: hold HIGH (default)
rw
1
[invert] Inversion • signal not inverted: do not invert
(default)
• signal inverted: invert
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] (n: 5...8).
w The menu page shows the current settings of the digital input filters on pin 2 and pin 4 of the
port.
u Set the parameters.
u Click on to save the changes to the device.
