Remote I/O module 8DO 8DI AL4322
19
6.3 Ethernet
The device is connected to the EtherNet/IP network via Ethernet ports XF1 / XF2 (e.g. EtherNet/IP
control, additional EtherNet/IP device). In addition, the device can be connected to an IT network via
the Ethernet ports. The user can access functions of the ifm IoT Core via the IT network (parameter
setting software, IoT Core Visualizer).
Wiring:
1 2
34
5
1: TX+
2: RX+
3: TX-
4: RX-
5: not used
u Connect the device to the EtherNet/IP network via a free Ethernet port.
u Optional: Connect the device to the IT network via a free Ethernet port.
u For connection, use an M12 connector (minimum protection rating: IP65 / IP66 / IP67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.4 Process connections (actuators)
The actuators are connected to the device via ports X1...X4.
The total current of ports X1...X2 and X3...X4 is limited to 4 A each.
The total current of ports X1...X4 is limited to 8A.
The ports feature both short-circuitand overload detection.
Wiring:
3
1 2
4
5
1: n.c.
2: Digital output 2 (DO2)
3: GND (UA)
4: Digital output 1 (DO1)
5: Functional earth (FE)
u Connect the actuators to ports X1...X4.
u For connection, use M12 connectors (minimum protection rating: IP65 / IP66 / IP67; max. cable
length: 30m).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.5 Process connections (sensors)
The sensors are connected to the device via ports X5...X8.
The total current supply of ports X5...X8 is limited to 3.6 A.
The ports feature both short-circuitand overload detection.
Wiring:
3
1 2
4
5
1: sensor supply L+ (US)
2: digital input 2 (DI2)
3: sensor supply L- (US)
4: digital input 1 (DI1)
5: functional earth (FE)
u Connect the sensors to ports X5...X8.
u For connection, use M12 connectors (minimum protection rating: IP65 / IP66 / IP67; max. cable
length: 30m).
u Tighten the cable plug using 1.3 ± 0.1Nm.
