AL4302 Remote I/O module 8DO 8DI
78
11.1.2.6 Submodule: Digital Output Energy Monitoring
Input data: 11 bytes
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
0 res. res. res. res. res. AUX PWR
Port 1&2
AUX PWR
Port 3&4
SENS PWR
1…2 Sensor Supply Voltage (US)
3…4 Sensor Suppy Current (US)
5…6 Actuator Supply Voltage (UA)
7…8 Port 1&2 Actuator Supply Current (UA)
9…10 Port 3&4 Actuator Supply Current (UA)
Legend:
• SENS PWR Error indication supply voltage US 1BIT • 0x0: no error
• 0x1: error
• AUX PWR Port 3&4 Error indication supply voltage UA - ports 3&4 1BIT • 0x0: no error
• 0x1: error
• AUX PWR Port 1&2 Error indication supply voltage UA - ports 1&2 1BIT • 0x0: no error
• 0x1: error
• Sensor Supply Voltage
(US)
Present voltage value of supply voltage US (in
mV)
Sensor Supply Voltage (US) = 0x1234
• Sensor Supply Voltage (US)[0] = 0x12
• Sensor Supply Voltage (US)[1] = 0x34
UINT16 • 0x0000: 0mV
…
• 0x0E10: 3600mV
• Sensor Supply Current
(US)
Present current value of supply voltage US (in
mA)
Sensor Supply Current (US) = 0x1234
• Sensor Supply Current (US)[0] = 0x12
• Sensor Supply Current (US)[1] = 0x34
UINT16 • 0x0000: 0mA
…
• 0x0E10: 3600mA
• Actuator Supply Voltage
(UA)
Present voltage of supply voltage UA (in mV)
Actuator Supply Voltage (UA) = 0x1234
• Actuator Supply Voltage (UA)[0] = 0x12
• Actuator Supply Voltage (UA)[1] = 0x34
UINT16 • 0x0000: 0mV
…
• 0x0E10: 3600mV
• Port 1&2 Actuator Supply
Current (UA)
Present current value of supply voltage UA -
ports 1&2 (in mA)
Port 1&2 Actuator Supply Current (UA) =
0x1234
• Port 1&2 Actuator Supply Current (UA)[0] =
0x12
• Port 1&2 Actuator Supply Current (UA)[1] =
0x34
UINT16 • 0x0000: 0mA
…
• 0x0E10: 3600mA
• Port 3&4 Actuator Supply
Current (UA)
Present current value of supply voltage UA -
ports 3&4 (in mA)
Port 3&4 Actuator Supply Current (UA) =
0x1234
• Port 3&4 Actuator Supply Current (UA)[0] =
0x12
• Port 3&4 Actuator Supply Current (UA)[1] =
0x34
UINT16 • 0x0000: 0mA
…
• 0x0E10: 3600mA
Output data: none
