Remote I/O module 8DO 8DI AL4302
43
w The menu page shows the current settings of the port’s counter module.
u Set the parameters.
u Click on to save the changes.
w The counter modules are configured.
9.2.3.4 Configuring the switching signal channels
u Observe the notes on switching signal channels: Switching signal channels (Ò/14)
Available parameters (Main SSC):
Name Description Value range Access
[mode] Main SSC - switching mode of the
switching channel
• Deactivated: switching channel
deactivated (default)
• Single Point: Single point mode.
• Latch: latch mode
• Two Point: Two point mode:
• Window: window mode
rw
1
[logic] Main SSC - switching logic of the
switching channel
• Active High: high active (default)
• Active Low: low active
rw
1
[sp1] Main SSC - switch point 1 • 0: 0
…
• 4294967295: 4294967295 (default)
rw
1
[sp2] Main SSC - switch point 2 • 0: 0
…
• 4294967294: 4294967294 (default)
rw
1
[single_point_edge] Main SSC - Defines whether the
switching channel reacts to increas-
ing or decreasing counter values
• Rising Counter Value: rising edge (default)
• Falling Counter Value: falling edge
rw
1
[switch_delay] Main SSC - switch delay (value in
ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[reset_delay] Main SSC - reset delay (value in
ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[hysteresis] Main SSC - hysteresis • 0: 0 (default)
…
• 4294967295: 4294967295
rw
1
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
Available parameters (batch SSC):
Name Description Value range Access
[mode] Batch SSC - switching mode of the
switching channel
• Deactivated: switching channel
deactivated (default)
• Single Point: single point mode.
• Latch: latch mode
• Two Point: two point mode
• Window: window mode
rw
1
[logic] Batch SSC - switching logic of the
switching channel
• Active High: high active (default)
• Active Low: low active
rw
1
[sp1] Batch SSC - switch point 1 • 0: 0
…
• 65535: 65535 (default)
rw
1
