AL4302 Remote I/O module 8DO 8DI
32
9.1.5 Process data
The dashboard area provides access to the device’s process data.
To display the dashboard area:
ü The parameter value editor for the device is open.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
To hide the dashboard area:
ü The dashboard area is displayed.
u Click on the vertical bar in the middle of the screen: Click on .
w The dashboard view is hidden.
9.1.5.1 Reading digital input data
Available information:
Name Description Value range Access
[digital] Signal level of the digital input chan-
nel (after filtering)
• LOW: off
• HIGH: on
ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w The view shows the current signal levels of the digital outputs at pin 2 and pin 4 in substructure [io/
port[n]] (n: 5...8).
The displayed signal levels are the filtered input data.
9.1.5.2 Writing the digital outputs
Available parameters:
Parameter Description Value range Access
[digital_output] Signal level of digital output channel • Low: LOW level
• High: HIGH level
rw
1
[qualifier] Status indication of digital output • Output error: Error
• Output okay: No error
ro
2
1
Read and write; parameter can only be changed if no connection to fieldbus controller is established
2
Read only
To write the digital outputs:
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
