AL4302 Remote I/O module 8DO 8DI
20
6.3 Ethernet
The device is connected to the PROFINET network via Ethernet ports XF1 / XF2 (e.g. PROFINET
control, additional PROFINET device). In addition, the device can be connected to an IT network via
the Ethernet ports. The user can access functions of the ifm IoT Core via the IT network (parameter
setting software, IoT Core Visualizer).
Wiring:
1 2
34
5
1: TX+
2: RX+
3: TX-
4: RX-
5: n.c.
u Connect the device to the PROFINET network via a free Ethernet port.
u Optional: Connect the device to the IT network via a free Ethernet port.
u For connection, use an M12 connector (minimum protection rating: IP65 / IP66 / IP67).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.4 Process connections (actuators)
The actuators are connected to the device via ports X1...X4.
Maximum current rating per port: 3.6A
Maximum current rating per port pair (X1&X2, X3&X4): 3.6A
Maximum overall current rating: 8 A
The ports feature both short-circuitand overload detection.
Wiring:
3
1 2
4
5
1: n.c.
2: OUT2 DO2 (UA)
3: L- (UA)
4: OUT1 DO1 (UA)
5: FE
u Connect the actuators to ports X1...X4.
u For connection, use M12 connectors (minimum protection rating: IP65 / IP66 / IP67; max. cable
length: 30m).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.5 Process connections (sensors)
The sensors are connected to the device via ports X5...X8.
Maximum current rating per port: 3.6A
Maximum overall current rating: 3.6A
The ports feature both short-circuitand overload detection.
Wiring:
3
1 2
4
5
1: L+ (US)
2: IN2 DI2
3: L- (US)
4: IN1 DI1
5: FE
u Connect the sensors to ports X5...X8.
