AL4242 Remote I/O module 8DO 8DI
82
11.1.1.16 Diagnostic Data (2000 - 2006)
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
2000 reserved res. res. res. res. res. res. PSE
UA
PSE
US
2001 Uptime
2002 Disconnection Counter
2003 US Voltage
2004 US Current
2005 UA Voltage
2006 UA Current
Legend:
• PSE US Power Status Error US: status of the
US supply voltage
1BIT / ro • 0x0: no error
• 0x1: Error
• PSE UA Power Status Error UA: status of the
UA supply voltage
1BIT / ro • 0x0: no error
• 0x1: Error
• Uptime Time since the last start of the device
(value in minutes)
1WORD /
ro
• 0x0000: 0 min
…
• 0xFFFF: 65535 min
• Disconnection
Counter
The counter for connection interrup-
tions (by user or by connection time-
out) since the last start of the device;
The counter is reset when the device
is restarted
1WORD /
ro
• 0x0000: 0 interruptions
…
• 0xFFFF: 65535 interruptions
• US Voltage Present voltage value of US supply
voltage (in mV)
1WORD /
ro
• 0x0000: 0mV
…
• 0x9C40: 40000mV
• US Current Current intensity value of the US sup-
ply voltage (value in mA)
1WORD /
ro
• 0x0000: 0mA
…
• 0x0E10: 3600mA
• UA Voltage Present voltage value of the UA sup-
ply voltage (value in mV)
1WORD /
ro
• 0x0000: 0mV
…
• 0x9C40: 40000mV
• UA Current Present current intensity value of the
UA supply voltage (value in mA)
1WORD /
ro
• 0x0000: 0mA
…
• 0x0E10: 3600mA
