AL4242 Remote I/O module 8DO 8DI
74
Mapping: SSC Configuration
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n SSC Main Mode
n+1 SSC Main Logic
n+2 SSC Main Single Point Edge
n+3 SSC Main SP1 (Word 0)
n+4 SSC Main SP1 (Word 1)
n+5 SSC Main SP2 (Word 0)
n+6 SSC Main SP2 (Word 1)
n+7 SSC Main Switch Delay
n+8 SSC Main Reset Delay
n+9 SSC Main Hysteresis (Word 0)
n+10 SSC Main Hysteresis (Word 1)
n+11 SSC Batch Mode
n+12 SSC Batch Logic
n+13 SSC Batch Single Point Edge
n+14 SSC Batch SP1
n+15 SSC Batch SP2
n+16 SSC Batch Switch Delay
n+17 SSC Batch Reset Delay
n+18 SSC Batch Hysteresis
Legend:
• SSC Main Mode SSC main counter - switching mode
of the switching channel
1WORD /
rw
• 0x0000: Deactivated (default)
• 0x0001: Single-point mode
• 0x0002: Latch mode
• 0x0003: Two-point mode
• 0x0004: Window mode
• SSC Main Logic SSC main counter - switching logic
of the switching channel
1WORD /
rw
• 0x0000: High Active (default)
• 0x0001: Low Active
• SSC Main Single Point
Edge
SSC main counter - reaction to in-
creasing of decreasing counter val-
ues
1WORD /
rw
• 0x0000: Rising counter value (default)
• 0x0001: falling counter value
• SSC Main SP1 SSC main counter - switching point
1
2WORD /
rw
• 0x00000000: 0
…
• 0xFFFFFFFF: 4294967295 (default)
• SSC Main SP2 SSC main counter - switch point 2 2WORD /
rw
• 0x00000000: 0
…
• 0xFFFFFFFE: 4294967294 (default)
• SSC Main Switch Delay SSC main counter – switch delay
(Wert in ms)
1WORD /
rw
• 0x0000: 0ms (default)
…
• 0xFFFF: 65535 ms
• SSC Main Reset Delay SSC main counter – reset delay
(value in ms)
1WORD /
rw
• 0x0000: 0ms (default)
…
• 0xFFFF: 65535 ms
• SSC Main Hysteresis SSC main counter – hysteresis 2WORD /
rw
• 0x00000000: 0 (default)
…
• 0xFFFFFFFF: 4294967295
