Remote I/O module 8DO 8DI AL4242
59
Mapping: Counter Data and Status
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n SSC Main Counter Value (Word 0)
n+1 SSC Main Counter Value (Word 1)
n+2 SSC Batch Counter Value
n+3 res. res. res. res. res. res. SSC
MC
OF
SSC
MC
UF
res. res. res. res. res. res. SSC
BC
OF
SSC
BC
UF
Legend:
• SSC Main Counter Value current counter value of the SSC main coun-
ter
2WORD
/ ro
• 0x00000000: 0
…
• 0xFFFFFFFE: 4294967294
• SCC Batch Counter Value current counter value of the SSC batch coun-
ter
1WORD
/ ro
• 0x0000: 0
…
• 0xFFFE: 65534
• SSC MC OF SSC Main Counter Overflow: Overflow event
at the SSC main counter
1BIT /
ro
• 0x0: no event
• 0x1: Overflow event
• SSC MC UF SSC Main Counter Underflow: Underflow
event at the SSC main counter
1BIT /
ro
• 0x0: no event
• 0x1: Underflow event
• SSC BC OF SSC Batch Counter SSC Overflow: Overflow
event at the SSC batch counter
1BIT /
ro
• 0x0: no event
• 0x1: Overflow event
• SSC BC UF SSC Batch Counter Overflow: Underflow
event at the SCC batch counter
1BIT /
ro
• 0x0: no event
• 0x1: Underflow event
