AL4242 Remote I/O module 8DO 8DI
54
• Main SSC - switching logic
• Main SSC - reaction to increasing / decreasing counter edges
• Main SCC - switch point SP1
• Main SCC - switch point SP2
• Main SCC - switch delay
• Main SCC - reset delay
• Main SCC - hysteresis
• Batch SCC - switching mode
• Batch SCC - switching logic
• Batch SCC - reaction to increasing / decreasing counter edges
• Batch SCC - switch point SP1
• Batch SCC - switch point SP2
• Batch SCC - reset delay
• Batch SCC - reset delay
• Batch SCC - hysteresis
u Only change the parameters [Main SP1], [Main SP2], [Main Hysteresis], [Main counter
threshold] and [Force Main Counter] with the function code 0x10 (Write Multiple Registers).
9.3.6 Configuring the digital outputs
Register range for the configuration of the digital output channels: Digital Output Configuration (1100 -
1123) (Ò/80)
Available parameters per output channel:
• Control instance for digital output channel
• Fallback value when connection is interrupted
• Max. output current value
9.3.7 Controlling the device
System commands can be executed on the device.
Register area for accessing the system commands: System Command (600) (Ò/71)
Available system commands:
• Restart the device.
• Resetting the device
9.3.8 Controlling the counter modules and switching channels
Register range for controlling the counter modules: Port Output - Counter (300 - 355)
Available control signals per counter module:
• Disable counter module
• Set the direction
• Reset overflow/underflow event of the main counter
• Reset overflow/underflow event of the batch counter
• Counter and overflow/underflow events Reset counter events
