AL4242 Remote I/O module 8DO 8DI
42
Name Description Value range Access
[pin2_function]
Pin 2 function of the port (Ò Observe
note!)
• N/C: no function (default)
• Counter edge input 2: counting pulse
(rising edge)
• Count direction: counting direction
• Reset (main & batch counter): reset
main counter and batch counter
• Disable (main & batch counter):
disable main counter and batch
counter
• Reset SSC Latch (Main & Batch
Counter): reset switching signal
rw
1
[count_direction_selection] Control instance for selecting the count-
ing direction (Ò Observe note!)
• Pin 2 count direction: pin 2 (default)
• IoT / PLC count direction: IoT Core /
Fieldbus PLC
rw
1
[main_threshold] Main counter threshold (CT) • 1
…
• 4294967295 (default)
rw
1
[batch_threshold] Batch counter threshold (CTb) • 1
…
• 65535 (default)
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] > [counter] (n: 5...8).
w The menu page shows the current settings of the port’s counter module.
u Set the parameters.
u Click on to save the changes.
w The counter modules are configured.
9.2.3.4 Configuring the switching signal channels
u Observe the notes on switching signal channels: Switching signal channels (Ò/14)
Available parameters (Main SSC):
Name Description Value range Access
[mode] Main SSC - switching mode of the
switching channel
• Deactivated: switching channel
deactivated (default)
• Single Point: Single point mode.
• Latch: latch mode
• Two Point: Two point mode:
• Window: window mode
rw
1
[logic] Main SSC - switching logic of the
switching channel
• Active High: high active (default)
• Active Low: low active
rw
1
[sp1] Main SSC - switch point 1 • 0: 0
…
• 4294967295: 4294967295 (default)
rw
1
[sp2] Main SSC - switch point 2 • 0: 0
…
• 4294967294: 4294967294 (default)
rw
1
