Remote I/O module 8DO 8DI AL4242
33
Name Description Value range Access
[maincounter_value] Main counter reading 0…4294967294 ro
1
[batchcounter_value] Batch counter value 0…65534 ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/counter[n]] (n: 5...8), the current counter values of the main and batch counters
are displayed.
9.1.5.4 Controlling counter modules
Available parameters:
Name Description Value range Access
[disable] Disable main counter and batch coun-
ter
• 0: counter module is active (default)
• 1: counter module is not active
rw
1
[reset] Reset main counter, batch counter
and CT and CTb thresholds to initial
values
• 0: no action (default)
• 1: reset
rw
1
[direction]
2
Set the counting direction for the main
counter and the batch counter
• 0: up (default)
• 1: down
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
2
only effective if operating mode of counter module = CTDIR
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/counter[n]] (n: 5...8), the available control signals of the counter modules are
displayed.
u Optional: Disable the counter module.
u Optional: Reset the counter module.
u Optional: Set the counting direction of the counter module.
u Write the changed parameter values to the device.
w The selected actions are executed.
9.1.5.5 Reading the switching signals
Available data:
Name Description Value range Access
[state] State of the switching signal • False: Off
• True: On
ro
1
1
Read only
Requirements:
