Remote I/O module 8DO 8DI AL4203
81
11.1.3.5 I&M data
I&M0 (Slot 0)
Index: 0xAFF0
Variable Description Value Bytes
MANUFACTURER_ID Manufacturer ID 0x136 2
ORDER_ID Order ID (ASCII, separated by spaces) AL4203 20
SERIAL_NUMBER Serial number (ASCII, separated by spaces) 16
HARDWARE_REVISION Hardware revision e.g. AA 2
SOFTWARE_REVISION Software revision
• Byte 0: software type (V: release)
• Byte 1: main version (uint8)
• Byte 2: minor version (uint8)
• byte 3: build version (uint8)
e.g. V1.0.3 4
REVISION_COUNTER Revision counter; counter is incremented with every parame-
ter change
0x0000 …
0xFFFF
2
PROFILE_ID Profile ID
• 0x0000: unspecific
0x0000 2
PROFILE_SPECIFIC_TYPE Profile type
• 0x0000: unused
0x0000 2
IM_VERSION I&M version
• 0x0101: V1.1
0x0101 2
IM_SUPPORTED Supported I&M data records
• 0x000: I&M0 is supported
• 0x00E: I&M0-3 are supported
• DAP:
0x000E
• Submodul
e: 0x0000
2
I&M1 (Slot 0)
Index: 0xAFF1
Variable Description Value Bytes
TAG_FUNCTION Identifier for function of the submodule
• 0x20: empty
0x20 32
TAG_LOCATION Identifier for location of the submodule
• 0x20: empty
0x20 22
I&M2 (Slot 0)
Index: 0xAFF2
Variable Description Value Bytes
INSTALLATION_DATE Installation date of the submodule (ASCII, separated by spac-
es)
• 0x20: empty
0x20 16
RESERVED reserved 0x00 38
I&M3 (Slot 0)
Index: 0xAFF3
Variable Description Value Bytes
DESCRIPTOR Description of the submodule (ASCII, separated by spaces)
• 0x20: empty
0x20 54
