Remote I/O module 8DO 8DI AL4203
77
11.1.3 Acyclical data
11.1.3.1 Data record: Filter configuration
Index: 300…307
Assignment of input channels to data record indices:
Index 310 311 312 313 314 315 306 307 308
Input
channel
Ch00 Ch01 Ch02 Ch03 Ch04 Ch05 Ch06 Ch06 Ch07
Per index:
Byte (Off-
set)
Bit
7 6 5 4 3 2 1 0
0…1 Debounce Time
2…3 Hold Time
4 res. res. res. res. res. res. Hold Level Input Invert-
er
Legend:
• Debounce Time Debounce time (= value * 0.1ms)
Debounce Time = 0x0123:
• Debounce Time[0] = 0x01
• Debounce Time[1] = 0x23
UINT16 / rc • 0x0000: 0 ms
…
• 0x01F4: 50 ms
• Hold Time Hold time (= value * 0.1ms)
Hold Time = 0x1234:
• Hold Time[0] = 0x12
• Hold Time[1] = 0x34
UINT16 / rc • 0x0000: 0 ms
…
• 0xEA60: 6000 ms
• Input Inverter inversion 1 bit / rc • 0x0: do not invert
• 0x1: invert
• Hold Level hold level 1 bit / rc • 0x0: hold LOW
• 0x1: hold HIGH
11.1.3.2 Data record: Counter configuration
Index: 500
Byte (off-
set)
Bit
7 6 5 4 3 2 1 0
0 Counter mode
1 Reserved Batch Event
enable
Main Event
enable
Count direction
1
|
Pin 2 function / Count direction
2
2..5 Main Treshold
6…7 Batch Threshold
1
only available for operating modes [CTU], [CTD] and [CTUD]
2
only available for operating mode [CTDIR]
Legend:
• Counter mode Operating mode counter module UINT8 / rc • 0x0: CTU – up counter
• 0x1: CTD – down counter
• 0x2: CTUD – up and down counter
• 0x3: CTDIR – up and down counter
with selectable counting direction
