AL4203 Remote I/O module 8DO 8DI
72
11.1.2.2 Submodule: CTU + SSC
Input data: 7 bytes
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
0…3 Main Counter Value
4…5 Batch Counter Value
6 Reserved Switching
Signal
Batch
Switching
Signal Main
Legend:
• Main Counter Value Current main counter value
Main Counter Value = 0x12345678
• Main Counter Value[0] = 0x12
• Main Counter Value[1] = 0x34
• Main Counter Value[2] = 0x56
• Main Counter Value[3] = 0x78
UINT32 • 0x00000000: 0
…
• 0xFFFFFFFE:
4294967294
• Batch Counter Value Current batch counter value
Batch Counter Value = 0x1234
• Batch Counter Value[0] = 0x12
• Batch Counter Value[1] = 0x34
UINT16 • 0x0000: 0
…
• 0xFFFE: 65534
• Switching Signal Main Switching signal main counter 1BIT • 0x0: LOW
• 0x1: HIGH
• Switching Signal Batch Switching signal batch counter 1BIT • 0x0: LOW
• 0x1: HIGH
Output data: 1 byte
Byte
(offset)
Bit
7 6 5 4 3 2 1 0
0 Reserved Reset Batch
SSC Latch
Reset Main
SSC Latch
Counter Di-
rection
Disable
Counter
Reset
Counter
Legend:
• Reset Counter Reset main counter and batch counter to initial
value
1BIT • 0x0: no action
• 0x1: reset
• Disable Counter Disable main counter and batch counter 1BIT • 0x0: no action
• 0x1: disable
• Counter Direction Set counting direction (only effective if parame-
ter [Count direction selection] = [PLC])
1BIT • 0x0: up
• 0x1: down
• Reset Main SSC Latch Reset switching channel main counter (only ef-
fective if parameter [Mode] = [Latch])
1 BIT • 0x0: no action
• 0x1: reset
• Reset Batch SSC Latch Reset switching channel batch counter (only ef-
fective if parameter [Mode] = [Latch])
1BIT • 0x0: no action
• 0x1: reset
