Remote I/O module 8DO 8DI AL4203
69
Submodule: CTDIR + SSC
Counter parameters:
Parameter Description Values Access
Enable Main counter
event
Notifications for main counter
• : disable
• : enable (default)
rw
1
Enable Main counter
event
Notifications for batch counter
• : disable
• : enable (default)
rw
1
Pin2 function / Count
direction selection
Notifications for main counter • Pin2 Count direction: (default)
• Pin2 Not used & Count Direction by PLC:
• Pin2 Reset Counter & Count Direction by
PLC:
• Pin2 Disable Counter & Count Direction by
PLC:
• Pin2 Reset SSC Latch & Count Direction by
PLC:
rw
1
Main Threshold Threshold CT of the main counter • 1
…
• 4294967295 (default)
rw
1
Batch Threshold Threshold CTb of the batch counter • 1
…
• 65535 (default)
rw
1
1
Read and write
Main SSC parameters:
Parameter Description Value range Access
Mode Switching mode of switching channel • Deactivated: switching channel deactivated
(default)
• Single Point: single point mode
• Latch: latch mode
• Two Point: two point mode
• Window: window mode
rw
1
Logic Switching logic of switching channel • High Active: (default)
• Low Active:
rw
1
Single Point Edge Defines whether switching channel
should react to rising or falling counter
values
• Rising Counter Value: rising counter values
(default)
• Falling Counter Value: falling counter values
rw
1
Set Point 1 Setpoint 1 0…4294967295 rw
1
Set Point 2 Setpoint 2 0…4294967294 rw
1
Switch Delay Switching delay (value in ms) 0…65535 rw
1
Reset Delay Reset delay (value in ms) 0…65535 rw
1
Hysteresis Hysteresis 0…4294967295 rw
1
1
Read and write
Batch SSC parameters:
Parameter Description Value range Access
Mode Switching mode of switching channel • Deactivated: switching channel deactivated
(default)
• Single Point: single point mode
• Latch: latch mode
• Two Point: two point mode
• Window: window mode
rw
1
Logic Switching logic of switching channel • High Active: (default)
• Low Active:
rw
1
