AL4203 Remote I/O module 8DO 8DI
60
11 Appendix
11.1 PROFINET
11.1.1 Parameters
11.1.1.1 Modules: 8DO / 8DI modules
Submodule: 8DO/8DI + qualifier
Per input channel:
Parameter Description Values Access
Debounce Time
[*0.1ms]
Debounce time (value * 0.1ms) • 0: 0ms (default)
…
• 500: 50 ms
rw
1
Hold time [*0.1ms] Hold time (value * 0.1ms) • 0: 0ms (default)
…
• 60000: 6000 ms
rw
1
Hold level Hold level • 0: Low: hold LOW
• 1: High: hold HIGH (default)
rw
1
Input Inverter Signal inversion • 0: Signal not inverted: do not invert signal
(default)
• 1: Signal inverted: signal inversion
rw
1
1
Read and write
Per output channel:
Parameter Description Value range Access
Digital Output Current
Limit
Max. current value of digital output (val-
ue in mA)
• 0: 0mA
…
• 1000: 1000mA (default)
…
• 3600: 3600mA
rw
1
Digital Output State
Communication Lost
Fall-back value if the connection to the
controller is interrupted
• Set OFF when communication lost: OFF
state (default)
• Set ON when communication lost: ON
state
• Keep last value when communication lost:
keep last valid state
rw
1
Digital Output Select Control instance for digital output • PLC: fieldbus control (default)
• MAIN SSC 1: switching channel main
counter 1
• BATCH SSC 1: switching channel batch
counter 1
• MAIN SSC 2: switching channel main
counter 2
• BATCH SSC 2: switching channel batch
counter 2
• MAIN SSC 3: switching channel main
counter 3
• BATCH SSC 3: switching channel batch
counter 3
• MAIN SSC 4: switching channel main
counter 4
• BATCH SSC 4: switching channel batch
counter 4
rw
1
