Remote I/O module 8DO 8DI AL4203
45
w The menu page shows the available information.
9.2.3.8 Setting the application tag
Available parameters:
Name Description Value range Access
[applicationtag] Device designation in monitoring software E.g. “factory 2 plant 1” rw
1
1
Read and write
32 bytes are available on the device for storing the applicationtag parameter. If the memory
range is exceeded, the device will abort the write process (diagnostic code 400).
u When writing the applicationtag parameter, observe the different memory requirements
of the individual UTF-8 characters (characters 0-127: 1 byte per character; character >127:
more than 1 byte per character).
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select the [devicetag] submenu.
w The menu page shows the current settings.
u Enter the application tag.
u Click on to save the changes to the device.
w The new application tag is set.
9.2.4 Accessing the process data
The [Processdata] menu page provides access to the process data of the device.
Requirements:
ü IoT Core Visualizer has been started.
u Select the [Processdata] menu.
w The menu page shows the substructures of the device description that contains the process data.
w The current process values are displayed.
