Remote I/O module 8DO 8DI AL4203
43
Name Description Value range Access
[sp2] Batch SSC - switch point 2 • 0: 0
…
• 65534: 65534 (default)
rw
1
[single_point_edge] Batch SSC - Defines whether the
switching channel should react to
increasing or decreasing counter
values
• Rising Counter Value: rising edge (default)
• Falling Counter Value: falling edge
rw
1
[switch_delay] Batch SSC - switching delay (value
in ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[reset_delay] Batch SSC - reset delay (value in
ms)
• 0: 0ms (default)
…
• 65535: 65535 ms
rw
1
[hysteresis] Batch SSC - hysteresis • 0: 0 (default)
…
• 65535: 65535
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü IoT Core Visualizer has been started.
ü The [Parameter] menu is active.
u Select submenu [io] > [port[n]] > [ssc] (n: 5...8).
w The menu page shows the current settings of the switching channels of the main counter
([main]) and the batch counter ([batch]) of the port.
u Set the parameters.
u Click on to save the changes.
w The switching signal channels are configured.
9.2.3.5 Configuring the digital outputs
Available parameters:
Parameter Description Value range Access
[current_limit] Max. output current of the digital out-
put (value in mA)
• 0: 0 A
…
• 1000: 1000mA (default)
…
• 3600: 3600mA
rw
1
[output_select] Selection of control instance of digital
output
• PLC: higher-level PLC
• Counter 1 SSC Main: Counter 1
switching channel - main counter
• Counter 1 SSC Batch: Counter 1
switching channel - batch counter
• Counter 2 SSC Main: Counter 2
switching channel - main counter
• Counter 2 SSC Batch: Counter 2
switching channel - batch counter
• Counter 3 SSC Main: Counter 3
switching channel - main counter
• Counter 3 SSC Batch: Counter 3
switching channel - batch counter
• Counter 4 SSC Main: Counter 4
switching channel - main counter
• Counter 4 SSC Batch: Counter 4
switching channel - batch counter
rw
1
