Je bekijkt pagina 33 van 82
Remote I/O module 8DO 8DI AL4203
33
u Write the changed parameter values to the device.
w The selected actions are executed.
9.1.5.5 Reading the switching signals
Available data:
Name Description Value range Access
[state] State of the switching signal • False: Off
• True: On
ro
1
1
Read only
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure [io/port[n]/ssc] (n: 5...8), the current states of the switching signals of the main
counter (main) and the batch counter (batch) of the port are displayed.
9.1.5.6 Controlling the switching signal channels
Available data:
Name Description Value range Access
[reset_latch] Reset switching signal (only effec-
tive if switch-point mode = latch)
• Inactive ➜ Active: reset switching signal
• otherwise: no action
rw
1
1
Read and write; parameter can only be changed if no active connection to fieldbus controller
Requirements:
ü The parameter setting software has been started.
ü The detailed view of the device is active.
u In the vertical bar at the right side of the screen: Click on .
w The dashboard view is displayed.
w In substructure io/port[n]/ssc (n: 5...8), the control signals for the switching channels of the
main counter (main) and the batch counter (batch) of the port are displayed.
u Set the control signals.
u Write the changed values to the device.
w The switching signal channels pass into the new state.
9.1.5.7 Reading status and diagnostic information
The measuring accuracy of the current and voltage values of the device supply US is ±10%.
Available information:
Parameter Description Value range Access
[temperature] Device temperature (value in °C) -30…80 ro
1
[supervisionstatus_us] Status of device supply US • 0: No error
• 1: Error
ro
1
