Remote I/O module 16 DI AL4143
45
The following exception codes are available:
Exception
code
Name Description
0x1 ILLEGAL FUNCTION Invalid Function Code (Modbus function not implemented)
0x2 ILLEGAL DATA ADDRESS Invalid data address (invalid address or length)
0x3 ILLEGAL DATA VALUE Invalid data value (invalid parameters; wrong number of registers)
0x4 SERVER DEVICE FAILURE Unrecoverable error in the Modbus server during processing
9.3.3 Configuring the device
Register areas for the basic settings of the device:
• Set the byte order in the data registers: Byte Swap (500) (Ò/58)
• Set the max. connection interruption time: Connection Timeout (510) (Ò/59)
• Set the arrangement of the process data in registers 0, 400 and 401: DI Channel Mapping (550)
(Ò/60)
9.3.4 Configuring digital inputs
Register range for the configuration of the digital input channels: Digital Input Configuration (100 - 163)
(Ò/51)
Available parameters for each digital input channel:
• Inversion
• Hold level
• Debounce time
• Hold time
9.3.5 Configuring counter modules
The register area 200...271 provides access to the settings of the counter modules of the ports:
Counter Configuration (200 - 271) (Ò/53)
Available parameters per counter module:
• Operating mode of the counter module
• Pin 2 function of the port
• Instance for selecting the counting direction
• Threshold CT of the main counter
• Threshold CTb of the batch counter
• Set counter value of the main counter
• Set the counter value of the batch counter
9.3.6 Reading process data
Registers 0...34 provide access to the unit's process data: Input data (0 - 34) (Ò/49)
The register range 0..2 contains the following process data:
• Digital inputs of all ports
• Overflow and underflow events of the main counter and batch counter of all ports
The register area 3...34 contains the following process data for each port separately:
