Remote I/O module 16 DI AL4043
53
Mapping: Counter Control
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n reserved res. res. res. res. res. res. res. DIS
n+1 reserved res. res. res. res. res. res. res. DIR
n+2 reserved res. res. res. res. res. res. res. RST
MC
OV
n+3 reserved res. res. res. res. res. res. res. RST
MC
UV
n+4 reserved res. res. res. res. res. res. res. RST
BC
OV
n+5 reserved res. res. res. res. res. res. res. RST
BC
UV
n+6 reserved res. res. res. res. res. res. res. RST
CT
Legend:
• DIS Disable Counter: disable main counter + batch
counter
1 BIT • 0x0: no action
• 0x1: disable main and batch counter
• DIR Counter Direction: Set counting direction (valid
only for counter mode CTDIR)
1 BIT • 0x0: up
• 0x1: down
• RST MC OV Reset Main Counter Overflow: Reset counter
event overflow of the main counter
1 BIT • 0x0: no action
• 0x1: Rest overflow event
• RST MC UV Reset Main Counter Underflow: Reset counter
event underflow of the main counter
1 BIT • 0x0: no action
• 0x1: Reset underflow event
• RST BC OV Reset Batch Counter Overflow: Reset counter
event overflow of the batch counter
1 BIT • 0x0: no action
• 0x1: Rest overflow event
• RST BC UV Reset Batch Counter Underflow: Reset counter
event underflow of the batch counter
1 BIT • 0x0: no action
• 0x1: Reset underflow event
• RST CT Reset Counter Module: Reset main counter
and batch counter to initial value
1 BIT • 0x0: no action
• 0x1: reset main + batch counter and
counter events to overflow/underflow
