Remote I/O module 16 DI AL4043
51
Mapping: Counter Configuration
Register
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n Counter Mode
n+1 Pin 2 Function
n+2 Counter Direction Select
n+3 Main Threshold (Word 0)
n+4 Main Threshold (Word 1)
n+5 Batch Threshold
n+6 Force Main Counter (Word 0)
n+7 Force Main Counter (Word 1)
n+8 Force Batch Counter
Legend:
• Counter Mode Operating mode of the counter
module
1 WORD • 0x0000: CTU – Up Counter (default)
• 0x0001:CTD – Down counter
• 0x0002: CTUD – Up and down counter
• 0x0003: CTDIR – Up or down counter
• Pin 2 Function Pin 2 function of the port 1 WORD • 0x0000: N/C - No function (default)
• 0x0001: counter edge input 2 – counting
input
• 0x0002: count direction – select counting
direction
• 0x0003: reset main + batch counter - reset
counter module
• 0x0004: disable main + batch counter –
disable counter module
• Counter Direction Select Instance for selecting the count-
ing direction
1 WORD • 0x0000: pin 2 (default)
• 0x0001: PLC
• Main Threshold Threshold CT of the main coun-
ter
MainThreshold = 0x01234567
• MainThreshold[0] = 0x0123
• MainThreshold[1] = 0x4567
2 WORD • 0x00000001: 1
…
• 0xFFFFFFFF: 4294967295 (default)
• Batch Threshold Threshold CTb of the batch
counter
1 WORD • 0x0001: 1
…
• 0xFFFF: 65535 (default)
• Force Main Counter Set counter value of the main
counter
ForceMainCounter =
0x01234567
• ForceMainCounter[0] =
0x0123
• ForceMainCounter[1] =
0x4567
2 WORD • 0x00000000: 0
…
• 0xFFFFFFFE: 4294967294 (default)
• Force Batch Counter Set counter value of the batch
counter
1 WORD • 0x0000: 0
…
• 0xFFFE: 65534 (default)
