Remote I/O module 16 DI AL4043
19
7.1.2 Ethernet
LED Description Colour State Description
LNK Status of the connection - Off No Ethernet connection
Green On Ethernet connection established
ACT Status of the data transmis-
sion
- Off No data transmission
Yellow Flashes Data transmission
7.1.3 Voltage supply
LED Description Colour State Description
US Power supply US status - Off No supply voltage is applied or the applied supply
voltage is too low (<4.5V)
Green On Supply voltage applied
Red On Overvoltage, undervoltage, short circuit at sensor
supply
7.1.4 Process connections
LED Description Colour State Description
DI1 Digital input signal level (pin
4)
Yellow Off Digital input - pin 4: LOW
On Digital input - pin 4: HIGH
DI2 Digital input signal level (pin
2)
Yellow Off Digital input - pin 2: LOW
On Digital input - pin 2: HIGH
