AL4043 Remote I/O module 16 DI
16
6.3 Ethernet
The device is connected to the ModbusTCP network via Ethernet ports X21 / X22 (e.g. ModbusTCP
control, additional ModbusTCP device). In addition, the device can be connected to an IT network via
the Ethernet ports. The user can access functions of the ifm IoT Core via the IT network (parameter
setting software, IoT Core Visualizer).
Wiring:
1 2
34
5
1: TX+
2: RX+
3: TX-
4: RX-
5: n.c.
u Connect the device to the ModbusTCP network via a free Ethernet port.
u Optional: Connect the device to the IT network via a free Ethernet port.
u For connection, use an M12 connector (minimum protection rating: IP65 / IP66 / IP67 / IP69K).
u Tighten the cable plug using 1.3 ± 0.1Nm.
6.4 Process connections
The sensors are connected to the device via the X01...X08 ports.
Maximum current rating of the ports: 3.6 A (for UL applications: 3.2 A).
The ports feature short-circuit/ overload detection.
u Connect the sensors to the X01...X08 ports.
u For connection, use M12 connectors (minimum protection rating: IP65 / IP66 / IP67 / IP69K; max.
cable length: 30m).
u Tighten the cable plug using 1.3 ± 0.1Nm.
Wiring:
3
1 2
4
5
1: L+ (US)
2: IN2 DI2
3: L- (US)
4: IN1 DI1
5: FE
6.5 Voltage supply
The device is connected to the US supply voltage via the Power IN port.
The US supply voltage supplies the device and the sensors connected to the ports X01...X08.
The X31 port is equipped with overvoltage protection (US).
The X31 port is equipped with reverse polarity protection (US).
The X31 port is equipped with an inrush current limitation.
Wiring:
43
2 1
1: L+ (US)
2: n.c.
3: L- (US)
4: n.c.
u Disconnect power.
u Connect the device via the X31 port to 24VDC (20...28V SELV/PELV).
u For connection, use an A-coded M12 connector (with at least protection rating: IP65 / IP66 / IP67 /
IP69K).
