Remote I/O module 16 DI AL4033
53
11.1.2.3 Input area (0x6000 - 0x6FFF)
Index Subindex Name Possible values
Data type /
access
0x6000 Inputs Module 1
• 0x01 Digital Input Channel 0…15 • Mapping: DI channel mapping - port-based
(Ò/54)
• Mapping: DI channel mapping - pin-based
(Ò/54)
BITARR16 /
ro
0x6010 Inputs Module 2
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6020 Inputs Module 3
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6030 Inputs Module 4
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6040 Inputs Module 5
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6050 Inputs Module 6
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6060 Inputs Module 7
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6070 Inputs Module 8
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
0x6080 Inputs Module 9
• 0x1 Main Counter Value
• Mapping: Main Counter Value (Ò/55)
UINT32 / ro
• 0x2 Batch Counter Value
• Mapping: Batch Counter Value (Ò/55)
UINT16 / ro
