AL4033 Remote I/O module 16 DI
50
Mapping: Flags
Word
(Offset)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
n reserved OI MS DE DW DI EE
Legend:
• EE Enable Emergency sending (acc. to ETG.1000-6) 1 BIT • 0x0: Do not transmit diagnostic messages
as emergency messages
• 0x1: Transmit new diagnostic message
as emergency message
• DI Disable information messages 1 BIT • 0x0: Information messages are stored in
the message queue (default)
• 0x1: Information messages are not stored
in the message queue
• DW Disable warning messages 1 BIT • 0x0: Warning messages are stored in the
message queue (default)
• 0x1: Warning messages are not stored in
the message queue
• DE Disable error messages 1 bit • 0x0: Error messages are stored in the
message queue (default)
• 0x1: Error messages are not stored in the
message queue
• MS Mode selection 1 bit • 0x0: Override Mode
• 0x1: Acknowledge Mode
• OI Overwrite/discard information Override Mode:
• 0x0: no event
• 0x1: Unacknowledged messages were
overwritten (buffer overrun); Subindex
0x03 = 0
Acknowledge Mode:
• 0x0: no event
• 0x1: Buffer is full of unacknowledged
messages and new messages are
discarded
