AL4033 Remote I/O module 16 DI
44
11 Appendix
11.1 EtherCAT
11.1.1 EtherCAT modules
11.1.1.1 Slot 1
Slot Description Available modules
Length
[bytes]
1 Digital input data • Deactivated: slot deactivated 0
• 8x2DI: digital input data activated (default) 2/0
11.1.1.2 Slot 2
Slot Description Available modules
Length
[bytes]
2 Counter module 1 • Deactivated: counter module port 1 deactivated (default) 0
• Counter 1: counter module port 1 activated 6/3
11.1.1.3 Slot 3
Slot Description Available modules
Length
[bytes]
3 Counter module 2 • Deactivated: counter module port 2 deactivated (default) 0
• Counter 2: counter module port 2 activated 6/3
11.1.1.4 Slot 4
Slot Description Available modules
Length
[bytes]
4 Counter module 3 • Deactivated: counter module port 3 deactivated (default) 0
• Counter 3: counter module port 3 activated 6/3
11.1.1.5 Slot 5
Slot Description Available modules
Length
[bytes]
5 Counter module 4 • Deactivated: counter module port 4 deactivated (default) 0
• Counter 4: counter module port 4 activated 6/3
11.1.1.6 Slot 6
Slot Description Available modules
Length
[bytes]
6 counter module 5 • Deactivated: counter module port 5 deactivated (default) 0
• Counter 5: counter module port 5 activated 6/3
