IO-Link input/output module AL2607
23
6 Electrical connection
The unit must be connected by a qualified electrician.
Observe the national and international regulations for the installation of electrical equipment.
Voltage supply according to SELV, PELV.
Do not apply external voltage to the outputs.
The device has digital type 3 inputs. Connected devices must be suitable for these inputs.
u Protect the UA voltage supply according to the maximum load and the ambient temperature
(maximum 16 A).
The characteristics of the fuse must correspond to the application.
u Use only UL-certified cables (CYJV or PVVA) with suitable data to connect the device.
6.1 Connecting the device
u Disconnect power.
u Connect the unit as follows:
M12 plug, A-coded, IO-Link (X1)
43
2 1
1: L+ (US)
2: not used
3: L- (US)
4: IO-Link
M12 connector, L-coded, voltage supply U
AUX
(X31)
3
1 4
2
5
1: not used
2: L- (UA)
3: not used
4: L+ (UA)
5: FE
M12 socket, A-coded, ports (X1.0...X1.7)
3
1 2
4
5
1: L+ (UA)
2: Multi-function port DI2, DO2, AI2
3: L- (UA)
4: Multi-function port DI1, DO1, FI*, PWM*, PWM-I*
5: FE
* only available in the [Acyclic Enhanced] operating mode
6.1.1 IO-Link connection
The IO-Link port must be connected according to the IO-Link specification.
6.1.2 Mounting the connector
The threaded connections in the device correspond to the M12 standard. To ensure compliance with
the specified protection rating, only cables that comply with this standard may be used. In the case of
self-assembled cables, the system manufacturer is responsible for the protection rating.
u Use connectors with gold-plated contacts.
u During installation, place the connectors vertically so that the coupling nut will not damage the
thread.
u Observe the coding of the connectors during installation.
If connector in the device:
