AL1921 IO-Link master with EtherNet/IP interface
98
11.2.2 Cyclic data
11.2.2.1 Input Assembly (Instance 100)
Byte (Off-
set)
Bit
7 6 5 4 3 2 1 0
0…1
Digital Input (Ò Mapping: Digital Input/101)
2…3
Status Information (Ò Mapping: Status Information/102)
4…45
Acyclic Command Channel: Response (Ò Response channel/109)
46…47
Port X01: Mapping: Port Qualifier Information (PQI) (Ò/103)
48…63
Port X01: Mapping: IO-Link information + events (Ò/103)
64…65
Port X02: Mapping: Port Qualifier Information (PQI) (Ò/103)
66…81
Port X02: Mapping: IO-Link information + events (Ò/103)
82…83
Port X03: Mapping: Port Qualifier Information (PQI) (Ò/103)
84…99
Port X03: Mapping: IO-Link information + events (Ò/103)
100…101
Port X04: Mapping: Port Qualifier Information (PQI) (Ò/103)
102…117
Port X04: Mapping: IO-Link information + events (Ò/103)
118…119
Port X05: Mapping: Port Qualifier Information (PQI) (Ò/103)
120…135
Port X05: Mapping: IO-Link information + events (Ò/103)
136…137
Port X06: Mapping: Port Qualifier Information (PQI) (Ò/103)
138…153
Port X06: Mapping: IO-Link information + events (Ò/103)
154…155
Port X07: Mapping: Port Qualifier Information (PQI) (Ò/103)
156…171
Port X07: Mapping: IO-Link information + events (Ò/103)
172…173
Port X08: Mapping: Port Qualifier Information (PQI) (Ò/103)
174…189
Port X08: Mapping: IO-Link information + events (Ò/103)
190 Port X01: Input data IO-Link (n bytes)
1
190+n Port X02: Input data IO-Link (n bytes)
1
190+2n Port X03: Input data IO-Link (n bytes)
1
190+3n Port X04: Input data IO-Link (n bytes)
1
190+4n Port X05: Input data IO-Link (n bytes)
1
190+5n Port X06: Input data IO-Link (n bytes)
1
190+6n Port X07: Input data IO-Link (n bytes)
1
190+7n Port X08: Input data IO-Link (n bytes)
1
1
n: {2, 4, 8, 16, 32}; n is determined by the parameter [Port Process Data Size] in the configuration assembly (Ò
Configuration Assembly (Instance 199)/95)
