AL1921 IO-Link master with EtherNet/IP interface
90
Parameter
Mandatory
field
Data type Description
index mandatory NUMBER IO-Link index of the parameter
subindex mandatory NUMBER IO-Link subindex of the parameter
Return ("data" field):
Parameter
Mandatory
field
Data type Description
value mandatory STRING Parameter value (value in hexadecimal format)
11.1.3.12 Service: iolwriteacyclic
Name: iolwriteacyclic
Description: The service acyclically writes the parameter value of an IO-Link device. It is accessed via
IO-Link index and subindex.
Request ("data" field):
Parameter
Mandatory
field
Data type Description
index mandatory NUMBER IO-Link index of the parameter
subindex mandatory NUMBER IO-Link subindex of the parameter
value mandatory STRING Parameter value (value in hexadecimal format)
Return ("data" field): none
11.1.3.13 Service: querytree
Name: querytree
Description: The service searches a device tree for the criteria profile , type and identifier and
outputs a list with the URLs of the elements found. At least one of the search criteria must be
specified. The service can only be executed on the root node of the unit.
Request (“data” field):
Parameter
Mandatory
field
Data type Description
profile Optional STRING Profile of the requested element
type Optional STRING Type of the requested element
identifier Optional STRING Name of the requested element
Response (“data” field): none
Parameter
Mandatory
field
Data type Description
urlList Mandatory ARRAY Array with URLs of the found elements; URLs are separated by com-
mas
11.1.3.14 Service: reboot
Name: reboot
Description: The service reboots the device.
Request (“data” field): none
Response (“data” field): none
