IO-Link master with EtherNet/IP interface AL1921
89
Parameter
Mandatory
field
Data type Description
security.activeConnec-
tion
Optional ENUM Connection type currently in use
• tcp_if: unencrypted http connection at the IoT interface, port
80
• tls_if: encrypted https connection at the IoT interface, port 443
• fb_if: unencrypted http connection at the fieldbus interface,
port 80
11.1.3.9 Service: gettree
Name: gettree
Description: The service reads the device description of the unit and outputs it as a JSON object. The
output can be limited to a subtree of the device description.
Request (“data” field):
Parameter
Mandatory
field
Data type Description
adr Optional STRING Root element of the subtree
level Optional STRING Max. level up to which the subtree is output
• no entry: all levels will be displayed
• 0: do not display sub-elements (“subs”)
• 1: display sub-elements
• 2: display sub-elements up to the 2nd level
• 3: display sub-elements up to the 3rd level
...
• 20: display sub-elements up to the 20th level
Response (“data” field):
Parameter
Mandatory
field
Data type Description
identifier Mandatory STRING Identifier of the root element
type Mandatory STRING Type of the element
format Optional JSON object Format of the data content
uid Optional STRING
profiles Optional JSON array
subs Mandatory JSON array Sub-elements
hash Optional STRING
11.1.3.10 Service: install
Name: install
Description: The service installs the firmware stored in a memory area of the unit.
Request ("data" field): none
Return ("data" field): none
11.1.3.11 Service: iolreadacyclic
Service: iolreadacyclic
Description: The service acyclically reads the parameter value of an IO-Link device. It is accessed via
IO-Link index and subindex.
Request ("data" field):
