AL1921 IO-Link master with EtherNet/IP interface
86
11.1.3 Services
11.1.3.1 Service: factoryreset
Name: factoryreset
Description: The service sets the parameters of the device to the factory settings.
Request (“data” field): none
Response (“data” field): none
11.1.3.2 Service: getsubscriberlist
Name: getsubscriberlist
Description: The service provides a list of all active subscriptions.
Request (“data” field): none
Response (“data” field):
Parameter
Mandatory
field
Data type Description
adr Mandatory STRING Notification trigger
datatosend Mandatory ARRAY OF
STRINGS
List with URLs of the data elements; URLs are comma separated
cid Mandatory STRING ID of the active notification
callbackurl Mandatory STRING Destination address for the notifications
duration Mandatory STRING Activity duration
11.1.3.3 Service: getsubscriptioninfo
Name: getsubscriptioninfo
Description: The service provides information about an active notification (subscribe). The following
parameters of the active notification are to be used for the query:
• cid (e.g. 4711)
• adr (e.g. timer[1]/counter/datachanged)
• callback (e.g. http://192.168.82.121:8080/topic)
Request ("data" field):
Parameter
Mandatory
field
Data type Description
callback mandatory STRING Destination address of the notifications; complete URL (e.g. http://ipad-
dress:port/path)
Return ("data" field):
Parameter
Mandatory
field
Data type Description
subscription mandatory BOOL Status of the transferred parameters of the notification
• FALSE: Parameter incorrect
• TRUE: Parameter correct; Notification found
datatosend mandatory STRING List with URLs of the data elements; URLs are comma separated
cid mandatory STRING ID of the active notification
callbackurl mandatory STRING Destination address of the notifications
