IO-Link master with EtherNet/IP interface AL1921
83
w New command can be executed.
9.4.7.2 Acyclic port commands
For the acyclic access to the configuration of the IO-Link port of the device, the following commands
are available:
Command Description Reference
Set Mode Set the operating mode of the IO-Link port
Set Mode (0x10) (Ò/112)
Set Validation ID / Data Storage Set the device validation and data storage Set validation ID / data storage (0x20)
(Ò/114)
Set Fail-safe Data Pattern Set the behaviour of the outputs when the Eth-
erNet/IP connection is interrupted and the cor-
responding fail-safe values
Set fail-safe data pattern (0x30)
(Ò/116)
The port commands use the mechanisms of the acyclic command channel.
9.4.7.3 EtherNet/IP mechanisms for acyclic commands
The device supports the acyclic access to the objects in the object directory, Object directory
(Ò/117). The EtherNet/IP command Message (MSG) can be used for acyclic read and write
access.
Detailed information on the Message (MSG) command: Ò User documentation RSLogix 5000
