IO-Link master with EtherNet/IP interface AL1921
77
u Select the [New Module…] menu item.
w A dialogue window appears.
u Select AL1921 and click [Create].
w The [New module] window appears.
u Configure the IP settings of the device.
u Save the project.
Setting the connection type
The connection type determines which object instances of Configuration Assembly (parameters), Input
Assembly (input data) and Output Assembly (output data) are used.
Available connection types:
Connection Description
Configuration
Assembly
Input Assembly
Output Assem-
bly
Exclusive Owner IO-Acyclic-
Diag
• Process data (inputs, outputs)
incl. PQI
• Acyclic data
• Diagnostic information, IO-Link
events
Instance 199 Instance 100 Instance 150
Exclusive Owner IO-Acyclic • Process data (inputs, outputs)
incl. PQI
• Acyclic data
Instance 199 Instance 101 Instance 150
Exclusive Owner IO • Process data (inputs, outputs)
incl. PQI
Instance 199 Instance 102 Instance 151
Input only • Process data (inputs) Instance 199 Instance 100 Instance 193
(empty)
Listen only • Process data (inputs) Instance 199 Instance 100 Instance 192
(empty)
The device only supports an active connection of the type Exclusive Owner. Connections of
type Listen only can be selected as the second active connection.
To set the connection type:
Requirements:
ü The project is open.
ü The device has been added to the project using the EDS.
u In the Controller Organizer: double-click on the [AL1x2x] node.
w A dialogue window appears.
u Click [Change…].
w The [Module Definition] window appears.
u Select the requested connection from the list [Connections].
u If necessary, set the data type to [INT].
u Click [OK] to adopt the changes.
w Based on the selected connection type, RSLogix 5000 generates the Controller Tags of the device
(Configuration, Input, Output).
Configuring the device
The device configuration includes the configuration of the IO-Link master and the IO-Link ports.
The parameters of the device are defined in the following object:
