IO-Link master with EtherNet/IP interface AL1921
133
Attr. ID Access Name Data type Description Default
11 Get / Set • AcdActivity USINT Condition of ACD activity at last conflict
detected
• 0: Noconflictdetected
• 1: ProbeIpv4Address
• 2: Ongoing Detection
• 3: SemiActiveprobe
• Remote MAC ARRAY(6)
of USINT
MAC address of the remote node of the
ARP PDU in which the conflict was de-
tected
• ArpPdu ARRAY(28)
of USINT
Copy of the data of the ARP PDU in
which the conflict was detected
13 Get / Set Encapsulation Inactivity Time-
out
UINT Inactivity before the TCP connection is
deactivated (in seconds)
120
Services
Code Service Class Instance Description
0x01 Get Attribute All No Yes Read all attributes
0x0E Get Attribute Single Yes Yes Read single attribute
0x10 Set Attribute Single No Yes Write single attribute
